single facer packing cartons making machine

electric heating Single Face Paper Corrugating Machine CorrugatedCartonMachine this kind single facer is mainly used in small size corrugated factory. Function 1. Introduction paper, powerfull fan, to center air source and electric control in one operating counter, 2. Corrugated roller is alloy steel, if quenching, gringding surface and plating chrome. 3. Surface of pressure roller treated with milling and plating chrome. 4. Surface of glue roller treated with network processing and plating chrome. Pneumatically gluing and circularly supplying glue. 5. Surface of scratch roller treated with plating chrome then ginding. 6. All the pressure roller made with special steel of Chengdu. 7. adopt metal host and rotary joint 8. Main motor adopts variable speed motor Technical parameters: 1. corrugated roll material 45CrMo, 2. plating chrome surface strength:HRC55-60 . 3. motor power 7.5 2. 4. adopts high temperature resistant international axletree of Harbin, Wa, Luoyang. 5. Adopts high temperature resistant grease. Well seal, stable. 6. Standard flute type: E flute height 1600mm, UVtype. 7. External dimensions 3000 1600 2600mm 8. Designed speed: 90m/min, economic speed: 60 m/min 9. Weight: about 3.2MT
